NSU Quickly: the moped that sold a million

NSU

NSU Quickly L
NSU Quickly L of 1956–1961. Photo by Lothar Spurzem, CC BY-SA 2.0 de via Wikimedia Commons.

The NSU Quickly was the moped that put West Germany on two motorised wheels. Made from 1953 to 1968 with a 49 cc two-stroke engine, pedals and a two-speed gearbox, it sold more than a million examples and appeared in a long series of versions.

NSU Quickly at a glance

NSU Quickly key facts
Maker NSU Motorenwerke AG, Germany
Production 1953–1968
Sold more than one million
Engine 49 cc two-stroke
Gearbox two speeds, three on some models
Frame pressed-steel single spar
Front suspension pressed-steel leading-link fork
Starting bicycle pedals
Quickly N 539,793 built, 1953–1962
Quickly S 314,715 built, 1955–1962
Quickly L 86,380 built, 1956–1961
Quickly T 38,605 built, 1959–1963

Based on one source: the English Wikipedia article on the NSU Quickly.

History of the NSU Quickly

The Quickly’s frame was a pressed-steel single spar: a headset at the front, arms reaching back to the wheel attachment points at the rear, and a tower in the middle which carried the seat post and provided the mountings for the engine unit and the petrol tank. The front forks were pressed steel with leading-link suspension. The engine unit combined a 49 cc two-stroke, a two-speed transmission — three speeds on some models — a set of bicycle pedals for starting and for help on hills, and a centre stand.

1958 NSU Quickly
NSU Quickly of 1958 in its original colours. Photo by Palauenc05, CC BY-SA 4.0 via Wikimedia Commons.

The original and simplest version was the Quickly N, with a 5.5:1 compression engine producing 1.4 PS at 4,600 rpm, a handlebar-operated two-speed gearbox and 26 × 2.00 inch wheels all round. NSU built 539,793 of them between 1953 and 1962, the single biggest block of Quickly production. The S of 1955 was essentially an N with larger mudguards, a speedometer, a side stand and chrome-plated rims; 314,715 were made up to 1962. The Dutch importer Van Oorschot assembled its own version with the front mudguard of the L, a different rear carrier and rare 25 × 2.25 inch wheels.

The L of 1956 was the luxury model. Its pressed-steel frame gained mountings for a swingarm and a unit combining the rear mudguard with spring and damper elements, so the rear wheel was finally suspended; leg shields were optional. 86,380 were built up to 1961. The Cavallino of 1957 went the other way, using the Quickly engine unit in a conventional tubular motorcycle frame with telescopic forks, a dual seat, a three-speed gearbox and 23 × 2.25 inch wheels; 21,584 were made until 1960.

The T of 1959 was nicknamed the TraumQuickly, the dream Quickly. It had its own frame and futuristic styling, a new leading-link fork with the front mudguard as a structural component, a three-speed gearbox and a high-compression engine (6.8:1) giving 1.7 PS at 5,000 rpm; 38,605 were built to 1963. The TT combined the Cavallino frame with the T’s front suspension and high-compression engine and was made from 1959 to 1963, while the TT/K, a TT with a kickstarter, accounted for 12,200 machines in 1960 and 1961.

The last years brought a family of revised models. The S2 of 1960 was an S with a dual seat, the T’s high-compression engine and 25 × 2.25 inch wheels, 12,411 built to 1962. The S/23 and S2/23 of 1961 had larger tanks, updated styling and 23-inch wheels, with 28,435 and 22,322 built respectively to 1963. The N/23 replaced the N in 1962 with 23 × 2.00 inch wheels and 11,347 built, and the F, or F/23, took over from the L at the top of the traditional line in 1962 and 1963, combining the L swingarm with the tall spring and damper units of the Cavallino and TT.

Design and features

  • Pressed-steel single-spar frame: one pressing carried headset, seat tower, engine and tank mountings.
  • Pedals: for starting the engine and for help on hills.
  • Engine unit: 49 cc two-stroke, two-speed gearbox and centre stand in one assembly.
  • Trim levels from basic to luxury: from the plain N to the rear-suspended L and the futuristic T.
  • More than a million sold: a genuine mass-market moped of the 1950s and 1960s.

NSU Quickly versions

  • Quickly N (1953–1962): 1.4 PS, two speeds, 26 × 2.00 wheels, 539,793 built.
  • Quickly S (1955–1962): larger mudguards, speedometer, side stand, chrome rims, 314,715 built.
  • Quickly L (1956–1961): rear swingarm suspension, optional leg shields, 86,380 built.
  • Quickly Cavallino (1957–1960): tubular motorcycle frame, telescopic forks, three speeds, 21,584 built.
  • Quickly T (1959–1963): the TraumQuickly, high-compression engine, three speeds, 38,605 built.
  • Quickly TT and TT/K (1959–1963): Cavallino frame with T parts; 12,200 TT/K built.

The Quickly followed the pre-war NSU Quick motor bicycle, and NSU’s scooters of the same years were the NSU Lambretta and the NSU Prima. More NSU models are in the NSU collection.
