The Nuffield 4 was the four-wheeled, four-cylinder member of the Universal family. It began as the petrol-paraffin M4 in 1948, became the 3.4-litre Universal 4 in 1952 and was sold in the Netherlands as the Nuffield “Vier”.
Nuffield 4 at a glance
| Maker | Agricultural Division, Morris Motors, Birmingham |
|---|---|
| Production | 1948–1961 (Universal range) |
| Layout | four wheels, four-cylinder engine |
| Original engine | 42 hp petrol-paraffin, Morris Commercial side-valve four |
| Diesel option | 38 hp Perkins P4, then 45 hp BMC from 1954 |
| Petrol version | PM4, 48 hp |
| Universal 4 (4DM) | 3.4-litre four-cylinder, 53 hp, from 1952 |
| Gearbox | five speeds |
| Extras | horn and lights charged at £9 |
| Dutch name | Nuffield “Vier” |
| Colour | “Poppy Orange” |
| Successor | 4/60 from 1961 |
Based on one source, the English Wikipedia article on the Nuffield Universal, which describes the four-cylinder models within the Universal range.
History of the Nuffield 4
When the Nuffield Universal was launched at the Smithfield Show in December 1948 it came in two forms: the tricycle-wheeled M3 for row-crop work and the conventional four-wheeled M4. The M4 was the version most farmers bought, and it set the pattern for the four-cylinder Nuffields that followed. Both used a five-speed gearbox and a 42 hp engine based on the side-valve Morris Commercial four-cylinder lorry unit, running on tractor vaporising oil; a horn and lights were extra, at £9.
The tractors were built in the former Wolseley factory in Birmingham, where Morris Motors had set up tractor production after car assembly moved to Cowley. The design came from Dr H. E. Merritt, a former David Brown engineer who had worked on the David Brown 50D and on tank design during the war, and the Nuffield therefore followed the layout of the new David Brown tractors. Paint was the bright red-orange the company called “Poppy Orange”.
A diesel was added in 1950 as the DM4, using a 38 hp Perkins P4 (TA). After Morris Motors joined the British Motor Corporation in 1951 the Perkins unit was kept until 1954, when it was replaced by a 45 hp BMC diesel; tractors with the new engine were recognisable by a “BMC Diesel” badge. A petrol-engined PM4 of 48 hp was sold alongside the diesel. In 1952 the range was re-engined again: the Universal 3 (3DL) took a 2.55-litre three-cylinder of 37 hp and the Universal 4 (4DM) a 3.4-litre four-cylinder of 53 hp.
Export sales began in earnest around 1950. In the United States Nuffield tractors were imported and rebadged by Long Manufacturing, while in the Netherlands they were first imported by Bautz and the Nuffield 4 was marketed there as the Nuffield “Vier”. In Spain the tractors carried Sava Nuffield branding. Production of the Universal range ended in 1961, when the four-cylinder role passed to the 4/60, the first Nuffield tractor built at Bathgate in Scotland.
Design and features
- Four wheels, four cylinders: the conventional layout that most buyers chose over the tricycle M3.
- Five-speed gearbox: standard across the petrol-paraffin and diesel versions.
- Choice of fuel: petrol-paraffin at first, then Perkins and BMC diesel and a 48 hp petrol PM4.
- Export identity: sold as the “Vier” in the Netherlands and rebadged in the United States.
- Poppy Orange: the bright red-orange paint used on every Nuffield of the period.
Nuffield 4 versions
- M4 (1948–1961): the original four-wheeled petrol-paraffin tractor, 42 hp.
- DM4 (1950–1961): diesel with a 38 hp Perkins P4, then a 45 hp BMC unit from 1954.
- PM4 (1950–1961): petrol version with a 48 hp engine.
- Universal 4 / 4DM (1952–1961): 3.4-litre four-cylinder, 53 hp.
The Nuffield 4 belongs to the Nuffield Universal family; its four-cylinder successor was the Nuffield 460, and the last of the line was the Nuffield 4/65. More tractors are in the Nuffield collection.
Video: Nuffield 4 cold start
Video on YouTube.
Sources
- Nuffield Universal, English Wikipedia: engines, variants, export markets, production years
