MOWAG Roland: the Swiss armoured carrier of the 1960s

MOWAG

Mowag Roland of the Mexican Army
A MOWAG Roland of the Mexican Army. Photo by ゴスロリ, CC BY-SA 4.0 via Wikimedia Commons.

The MOWAG Roland is an armoured personnel carrier of Swiss origin, developed in 1960 with a prototype tested in 1963 and series production running from 1964 to 1980. It was designed to serve as an ambulance, reconnaissance vehicle, troop carrier, riot-control vehicle and rocket launcher.

MOWAG Roland at a glance

MOWAG Roland key facts
Maker MOWAG, Switzerland
Designed 1960
Prototype tested 1963
Production 1964–1980
Type armoured personnel carrier
Engine position rear, left side
Armament customer-specific: 7.62 mm or 12.7 mm machine gun, or none
Roles APC, ambulance, reconnaissance, riot control, rocket launcher
Built over 500
Main users Argentina, Bolivia, Chile, Greece, Mexico, Peru, Switzerland

Based on a single source, the short English Wikipedia article on the Roland; the article is briefer than the usual model history and the page follows it closely.

History of the MOWAG Roland

MOWAG developed the Roland in 1960 and tested the prototype in 1963. Production began in 1964 and continued until 1980, by which time more than 500 vehicles had been built and shipped to Argentina, Bolivia, Chile, Greece, Mexico, Peru and to various police departments in Switzerland.

The vehicle was laid out around its roles rather than around a single weapon. The engine sits at the rear on the left side, and the doors for the crew and passengers are on the right side at the rear and on the left side of the vehicle. A searchlight is mounted on the front, with a rotary roof section behind it for a machine gun or a heavier weapon operated by the commander.

The Roland was sold with a gun only when the customer asked for one: armament could be an assault rifle or a machine gun such as a calibre .50 heavy machine gun, a calibre .30 Browning, an M60 or a general-purpose machine gun. Police vehicles usually carried no gun at all, but were fitted with a siren, blue light, searchlight, loudspeakers and a V-shaped dozer blade for clearing obstacles.

Some African operators equipped their Rolands with multiple rocket launchers for five unguided rockets. In the Swiss Military Museum at Full a Roland of the Bern Cantonal Police is displayed with a plough attached; that vehicle remained in use until 1997.

Design and features

  • Rear engine: mounted on the left, which keeps the crew compartment clear.
  • Rotary roof mount: for a machine gun or heavier weapon, worked by the commander.
  • Front searchlight: standard equipment, with the weapon mount directly behind it.
  • Side and rear doors: for quick mounting and dismounting of the crew.
  • Police fittings: siren, blue light, loudspeakers and a V-shaped dozer blade.

MOWAG Roland versions

  • Standard army APC: armoured troop carrier with a machine-gun mount.
  • Armoured ambulance: casualty transport version.
  • Riot and crowd control vehicle: siren, blue light, loudspeakers and dozer blade, usually unarmed.
  • Rocket version: South African and other African vehicles with five-round launchers.
  • Mexican Army vehicles: 25 ordered in 1976 with a turret for a 7.62 mm FN MAG, and 5 rocket-launcher vehicles.

The Roland was an earlier MOWAG design than the Mowag Piranha, the wheeled family that followed it. More vehicles are collected in the Mowag section.
