Moto Morini Corsaro: the 125 that carried the firm through the 1960s

MOTO MORINI

1964 Moto Morini 125 Corsaro
1964 Moto Morini 125 Corsaro. Photo by Mr.choppers, CC BY-SA 3.0 via Wikimedia Commons.

The Moto Morini Corsaro is the 125 cc four-stroke that replaced the two-stroke 125 Turismo in 1959 and stayed in production until 1974. It was the bike that made Morini’s name in the 1960s, in road, scrambler and Regolarità form, and the name was brought back for the first model of the reborn firm in 2005.

Moto Morini Corsaro at a glance

Moto Morini Corsaro key facts
Made by Moto Morini, Bologna, Italy
Production 1959–1974
Replaced the two-stroke Moto Morini 125 Turismo
Engine 125 cc air-cooled single, four-stroke, pushrods and rockers
Bore and stroke 56 × 50 mm
Engine origin the 98 cc single of the 1956 Sbarazzino, bored out
Frame open-cradle tubular steel, new for the model
1963 update Corsaro Veloce, 9 hp, 115 km/h
150 cc version from 1964, 58 × 54 mm, 142.6 cc
Gearbox four speeds, five from 1969
Export names Cyclone, Jaguar and Hurricane in the United States
Replaced by the 125 H of 1975, with an engine derived from the 3½

There is no English Wikipedia article on the Corsaro; this page is based on the Italian article. It covers the 1959–1974 Corsaro, not the 1200 of 2005.

History of the Moto Morini Corsaro

A new 125 for 1959

1961 Moto Morini Corsaro 125
1961 Moto Morini Corsaro, 125 cc. Photo by Lothar Spurzem, CC BY-SA 2.0 de via Wikimedia Commons.

The Corsaro was built to replace the 125 Turismo, a two-stroke that dated from the early 1950s. Its engine came from the Sbarazzino of 1956, a 98 cc four-stroke single with pushrods and rockers, taken out to 125 cc with a 56 mm bore and a 50 mm stroke. The frame was entirely new: an open-cradle tubular chassis where the Sbarazzino had used pressed-steel parts. The new Bologna 125 was quick enough for its class and sold well.

In 1963 came the Corsaro Veloce, with revised styling and an engine tuned to 9 hp, enough for 115 km/h. The following year the range was widened with a 150 cc model, 58 × 54 mm and 142.6 cc. Around the same time Morini began exporting the Corsaro to the United States, where it was sold as the Cyclone, the Jaguar and the Hurricane.

The last road versions

In 1969 the Corsaro range was completely revised. There were two levels, the Sport Lusso in 125 cc only and the Super Sport in 125 and 150, and in both cases the gearbox went from four speeds to five. The Corsaro Country of 1970 was a scrambler that combined the Super Sport engine with the frame of the Regolarità version, and in 1972 the sporting Corsaro Special appeared with the 125 and 150 engines. Production ended in 1974, when the Corsaro was replaced by the 125 H, whose engine came from the new 3½ V-twin.

The Regolarità

Morini also built an off-road Corsaro. The first version of 1962 was little more than a scrambler; the specialist machine arrived at the Milan show of 1965, with a closed double-cradle frame and better suspension, and in 1966 it won its class at the Valli Bergamasche and a gold medal at the Six Days, with a 150 cc version added that year. In 1967 the model was redesigned again, with a new frame, bodywork and a revised engine in 100, 125 and 150 cc, and the Morinis of Edoardo Dossena, Giovanni Collina and Giuseppe Gritti won the Italian championship in all three classes, plus four gold medals at the Six Days. For 1968 the 150 was enlarged from 142.6 to 153.2 cc by lengthening the stroke, and the Corsaro took the Italian 100 and 125 titles plus seven gold medals at the Six Days of San Pellegrino Terme. The 1969 version had a stronger frame, five gears and new bodywork and took four Italian titles in 1969 and 1970. The last revision of 1971 used a lighter Verlicchi frame, Marzocchi suspension and a 21-inch front wheel, dropped the 100 and took the 150 to 163.9 cc; the Regolarità went out of production in 1972, and Morini had no off-road model again until the Camel of 1981.

Design and features

  • Pushrod four-stroke single: a simple, reliable 125 that could be tuned for road or competition use.
  • New tubular frame: an open cradle in place of the pressed-steel chassis of the Sbarazzino.
  • Racing record: Italian championships in 1967, 1968, 1969 and 1970 and gold medals at the Six Days.
  • Export names: Cyclone, Jaguar and Hurricane for the American market.

Moto Morini Corsaro versions

  • Corsaro 125 (1959): the original road model.
  • Corsaro Veloce (1963): 9 hp and 115 km/h, with revised styling.
  • Corsaro 150 (1964): the enlarged 142.6 cc version.
  • Corsaro Sport Lusso and Super Sport (1969): five-speed gearboxes and new bodywork.
  • Corsaro Country (1970): a scrambler with the Super Sport engine and the Regolarità frame.
  • Corsaro Regolarità (1962–1972): the works off-road machine, in 100, 125, 150 and finally 163.9 cc.

The Corsaro was replaced by the 125 H, whose engine came from the 3½, and the earlier 125 models are collected in our article on the Moto Morini 125. The off-road line continued with the Camel; more models are in the Moto Morini collection.
